Pakistan Cables 1.5mm Solid Pure Copper Wire – 90m Coil (Best Price House Wiring)
Rs.9,796.00
Description
Pakistan Cables 1.5mm solid copper wire – the most reliable single core wire for house earthing, lighting circuits, fans, and low-power domestic wiring. 99.99% pure solid copper conductor (1.5mm² cross-section) with flame-retardant PVC insulation (450/750V rating) – preferred by electricians for safety-critical earthing and general wiring in Karachi, Lahore, and across Pakistan.
Why 1.5mm Solid? Perfect for Earthing + Light Circuits
-
Earthing wire for main panels, MCBs, appliances
-
Lighting circuits (LEDs, tube lights)
-
Switchboards, distribution boxes
-
Fans, exhaust fans
-
Low-power sockets (mobile chargers, night lights)
Pakistan Cables 1.5mm Solid Technical Specifications
Conductor: 99.99% Pure Solid Copper (1.5mm²)
Gauge: 1.5mm solid round (IEC standard)
Insulation: FR PVC (Flame Retardant 70°C)
Voltage Rating: 450/750V AC
Coil Length: Exact 90 meters guaranteed
Ampacity: 15-18A (lighting + earthing)
Colors Available: Green/Yellow (earth), Black, Red, Blue
Standards: BS 6004, IEC 60227 certified
Weight: 1.8-2.2kg per coil
Load Capacity Guide
✅ 100+ LED lights per circuit
✅ 10-12 ceiling fans
✅ Earthing for main panel + sub-panels
✅ 6-8 low-power sockets
✅ Switch drop wires
NOT recommended for: ACs, water pumps, heavy appliances (use 2.5mm)
1.5mm Solid vs 3/29 Stranded Comparison
| Feature | 1.5mm Solid | 3/29 Stranded |
|---|---|---|
| Copper Type | Solid Round | 3 Twisted Strands |
| Flexibility | Stiff (fixed wiring) | Flexible |
| Earthing | ✅ Perfect | Good |
| Lighting Circuits | ✅ Excellent | Good |
| Price/Coil | Lower | Higher |
| Termination | Easy crimping | Slightly complex |
Why Pakistan Cables 1.5mm Solid?
✅ 99.99% Pure Solid Copper (no strands to break)
✅ Exact 90m coil length guaranteed
✅ FR PVC insulation (fire safe up to 70°C)
✅ Perfect for earthing (IEC compliant)
✅ 25+ year lifespan in conduitInstallation Benefits:
-
Easiest termination (no strand fanning)
-
Zero breakage in conduits
-
Perfect earth connection (solid contact)
Installation Guide
1. Strip 10-12mm insulation cleanly
2. Insert full conductor in earth terminal
3. No ferrules needed (solid copper)
4. Torque 1.0-1.2 Nm for MCB earth bars
5. Green/Yellow color = instant identification
6. Test <1 ohm resistance to earth plateFrequently Asked Questions
Q: Solid or stranded – which is better for earthing?
A: 1.5mm solid = best for earthing. Solid contact, no loose strands.
Q: Can I use for lighting circuits?
A: Perfect for LEDs, tube lights, fans (15A safe).
Q: Coil length exact?
A: Guaranteed 90 meters – Pakistan Cables factory standard.
Q: Pure copper confirmed?
A: 99.99% pure solid copper – BS 6004 certified.
Q: Indoor/outdoor use?
A: Indoor only or conduit-protected outdoor. Not direct burial.
Q: Karachi delivery?
A: FREE same day Karachi. Nationwide 2-3 days COD.
Q: Compared to 2.5mm?
A: 1.5mm = earthing/lighting. 2.5mm = ACs/pumps.
Q: Green/Yellow color mandatory?
A: Yes for earthing (IEC standard). Black/Red for live/neutral.
